Axle-Truck-Scales
One deck axle type trucks scale with 3.2* 2.2m platform dimensions at affordable
UGX 1,500,000
UGX 2,000,000
In Stock
Description
Our Dynamic Weighing System for Commercial Trucks is designed to accurately measure vehicle weights in motion, helping logistics operators, fleet managers, and industrial sites improve efficiency, reduce congestion, and ensure compliance without stopping vehicles. Ideal for high-traffic environments, this system enables fast, reliable weighing while maintaining smooth vehicle flow.
Using advanced sensors and precision load cell technology, the dynamic weighing system captures axle weights, gross vehicle weight, and overload conditions as trucks pass over the weighing platform at controlled speeds. Real-time digital data is displayed instantly and can be integrated with traffic management, access control, and fleet monitoring systems.
Built for durability and outdoor operation, the system is suitable for logistics hubs, ports, industrial facilities, and compliance checkpoints. With minimal driver intervention required, dynamic weighing reduces waiting times, improves throughput, and enhances operational productivity.
Ideal for use in:
Logistics and distribution centres
Fleet depots and transport yards
Ports and container terminals
Industrial and manufacturing sites
Overload control and compliance stations
Key Benefits:
Weighs commercial trucks while in motion
Reduces congestion and vehicle waiting times
Improves throughput in high-traffic operations
Accurate axle and gross vehicle weight measurement
Integrates with fleet management and control systems
Designed for continuous outdoor operation
Specifications
| Specifications (Typical) | |
| Weighing Type | Dynamic (in-motion weighing) |
| Vehicle Speed Range | Typically, 5 – 15 km/h (system dependent) |
| Maximum Capacity | Up to 80,000 kg (80 tonnes) |
| Accuracy | ±1–3% (application and speed dependent) |
| Measured Parameters | Axle weight, group axle weight, gross vehicle weight |
| Sensor Technology | High-precision load cells / piezo or quartz sensors (model dependent) |
| Platform Construction | Steel or concrete-mounted sensors |
| Indicator & Software | Digital display with data logging and reporting software |
| Data Output | Ethernet / RS232 / USB (integration options available) |
| Power Supply | Mains power with optional UPS |
| Ingress Protection | IP68 sensors, IP65 electronics |
| Operating Environment | Outdoor industrial and commercial applications |
| Installation | Surface-mounted or embedded (site dependent) |
| Maintenance | Low maintenance, designed for continuous operation |
| Compliance | Trade-approved / enforcement options available (model dependent) |
