⚙️ Standard 5 Ton Digital Crane Hanging Scale – Specifications
🏋️ Capacity & Load Performance
- Maximum Capacity: 5 tons (5 000 kg / 11 023 lb) – robust industrial load handling.
- Resolution / Division: Typically 2 kg increments for accurate large‑load measurement.
- Minimum Load: Depends on model (e.g., ~40 kg or lower).
- Accuracy Standard: Meets industrial precision (OIML Class III or equivalent).
- Safe Overload: ~125 % of full scale rating without damage.
- Ultimate Overload: Up to ~400 % of full scale in emergency tolerance.
🖥️ Display & Units
- Display Type: Large LED or backlit LCD digital display with clear digits, easy to read from a distance.
- Digits: 5‑digit screen for weight clarity.
- Units Supported: Switchable between kg / lb (some models also support N or tonne units).
💡 Weighing & Smart Functions
- Tare Function: Deducts the weight of hooks or slings for net weight.
- Zero / Auto‑Zero Tracking: Ensures a stable baseline before weighing.
- Hold / Peak Hold: Locks a stable weight reading on screen.
- Overload Alarm: Alerts when load is near or above safe limits.
- Auto Power‑Off: Saves battery when idle (model dependent).
🔋 Power & Operation
- Battery Type: Rechargeable sealed battery (commonly 6 V / 4–10 Ah depending on model).
- Battery Life: Typically ~80–100+ hours per charge.
- Charger: AC adaptor included (e.g., 9 V DC input).
- Low‑Battery Indicator: Alerts when battery needs recharge.
🛠️ Construction & Durability
- Housing: Heavy‑duty aluminum alloy or steel body for impact resistance and long service life.
- Hook & Shackle: Reinforced high‑strength steel or stainless steel with safety latch for secure load attachment.
- Operating Temperature: Approx. ‑10 °C to +40 °C (varies by model).
- Operating Humidity: Up to ~85–90 % relative humidity.
📊 Typical Technical Overview
|
Specification |
Typical Value |
|
Capacity |
5000 kg / 5 tons |
|
Resolution / Division |
2 kg |
|
Display |
LED / Backlit LCD |
|
Units |
kg / lb switchable |
|
Functions |
Tare, Zero, Hold, Overload alarm |
|
Battery |
Rechargeable (~6 V / 4–10 Ah) |
|
Battery Life |
~80–100+ h |
|
Housing Material |
Aluminum alloy / Heavy‑duty steel |
|
Overload Safety |
~125 % F.S. safe, ~400 % ultimate |
|
Operating Temp. |
–10 °C to +40 °C |
🏭 Typical Uses
5 Ton Digital Crane Hanging Scales are ideal for:
✔ Heavy weight measurement in warehouses & logistics
✔ Factories & manufacturing heavier components
✔ Shipping & freight handling
✔ Construction materials weighing
✔ Industrial workshops & load testing
✔ Scrap, steel, timber or bulk material weighing
These specs are typical for commercial industrial crane scales; exact values may vary by manufacturer or model.
