When weighing both sheep and horses, the primary challenge is the vast difference in their behavior and size. While sheep are small and "flighty," horses are heavy and require a low-profile, noise-dampened surface to prevent spooking.
1. Recommended Horse & Sheep Floor Scales
For a setup that covers both species up to 500kg with 0.1kg precision, look for these specific models available in 2026:
- BOSCHE PW-1500 (The Gold Standard): * Capacity: 1,500kg (ideal for horses) with high-precision options.
- Specs: Extra-long platform (200cm x 112cm) to fit a horse's full stride.
- Horse-Safe: Comes with an integrated sound-absorbing rubber mat so the "clack" of hooves on metal doesn't startle the horse.
- Brecknell PS3000-LCD:
- Capacity: 1,500kg.
- Specs: 200cm x 100cm platform.
- Key Feature: Low-profile (under 10cm high) with included ramps, making it easy for both sheep and horses to step on without hesitation.
- VEVOR / PS-500 (Economy Option):
- Capacity: 500kg x 0.1kg.
- Specs: 103cm x 53cm.
- Note: This is excellent for sheep and foals, but the platform is too small for an adult horse. For adult horses, you must use a "Weigh Bridge" or "Weigh Beam" system.
2. Dual-Purpose Fence Specifications
If you are building a cage around your scale to handle both sheep and horses, you need a hybrid design:
|
Feature |
Sheep Requirement |
Horse Requirement |
Hybrid Recommendation |
|
Fence Height |
0.9m (35") |
1.6m+ (63"+) |
1.5m (60") with a top rail. |
|
Siding |
Sheeted (Solid) |
Open Rails |
Sheeted bottom 60cm (keeps sheep moving) + Open top rails (prevents horse claustrophobia). |
|
Gate Type |
Sliding / Guillotine |
Heavy Swing Gate |
Swing Gate with a heavy-duty spring latch. |
|
Width |
50cm (Narrow) |
100cm+ (Wide) |
Adjustable width or 90cm (wide enough for horses, but requires a handler for sheep). |
3. Critical Features for Multi-Species Use
- The "Dampening" Factor: Ensure your indicator has Superdamp™ or "Animal Hold" technology. Horses have a slow, heavy heartbeat that can oscillate a scale, while sheep have fast, jittery movements. The software must be able to filter both.
- Non-Slip Surface: While a "checker plate" (diamond plate) steel floor is standard, it is slippery for horses. Always use a heavy-duty rubber mat (8mm–10mm) on top of the scale.
- Load Cell Protection: For horses, ensure the load cells are "Shear Beam" style with a high overload rating (150% minimum). A horse shifting its weight suddenly can exert a force much higher than its standing weight.
4. Setup Tip: The "Mobile" Weighing Station
If you need to weigh sheep in the field and horses in the stable, consider Weigh Beams (two long bars) rather than a flat platform. You can place a lightweight aluminum crate on them for sheep, or a large plywood/rubber platform for horses.
