For a professional veterinary or farm setup, a 500kg platform scale with 0.1kg (100g) accuracy provides the perfect balance between high capacity and precision. This setup is ideal for larger dogs, sheep, goats, pigs, and calves.
Top-Rated Digital Platform Models (500kg x 0.1kg)
|
Model / Type |
Platform Size |
Key Features |
Approx. Price |
|
PS-500 Series (Industry Standard) |
103 x 53 cm |
Stainless steel, Dynamic Hold, RS232 port, low profile. |
$170 – $250 |
|
VEVOR 1100LB |
110 x 52 cm |
Waterproof indicator, dual-range accuracy, portable handles. |
$145 – $180 |
|
KERN EOE 500 |
95 x 50 cm |
High-end German engineering, wall-mount display, very stable. |
$350 – $500 |
|
BSS Stainless |
Custom Sizes |
IP68 Waterproof load cells, full washdown safe (Vet Clinic grade). |
Quote based |
Technical Specifications for Veterinary Use
To ensure clinical accuracy and animal safety, look for these specific technical standards:
- Animal Weighing (Dynamic Hold): Essential for veterinary use. It calculates an average weight over 2–3 seconds to compensate for a moving animal, freezing the result on the screen.
- Accuracy/Readability: You specified 0.1kg. Ensure the scale maintains this throughout the full range; some cheaper models drop to 0.2kg or 0.5kg accuracy once you pass the 250kg mark.
- Platform Construction: A 304 Grade Stainless Steel top is the gold standard for hygiene. It resists corrosion from animal waste and harsh veterinary disinfectants.
- Power Versatility: Look for "Dual Power"—an AC adapter for the clinic and a battery compartment (usually 4–6 AA batteries) for use in the field or barn.
Important Setup Requirements
- Non-Slip Surface: Stainless steel is slippery when wet. Most veterinary scales include a removable rubber mat. Ensure this mat is used during weighing but removed for cleaning.
- The "Flight" Gap: If building this into a race or a chute, ensure there is a 1cm gap between the platform and the surrounding floor/fencing. If the scale touches a wall or fence, the weight will "bind" and give a false low reading.
- Cable Protection: Livestock often chew on cables. If using this on a farm, consider running the display cable through a PVC conduit or choosing a model with a reinforced braided cable.
