The Industrial Truck Scale Weighbridge from Accurate Weighing Scales Ltd is a heavy-duty, precision-engineered vehicle weighing solution built to handle the toughest industrial environments. Designed for accurate measurement of trucks, trailers, and heavy equipment, this robust weighbridge delivers reliable performance and long-lasting durability for logistics centres, factories, mining and quarry sites, ports, agricultural hubs, and commercial weigh stations.
Built with reinforced structural steel, high-precision load cells, and advanced digital electronics, the Industrial Truck Scale Weighbridge ensures consistent and accurate weight data you can trust — whether you’re checking compliance with legal weight limits, optimising payloads for efficiency, or recording vehicle weight for reporting and operational decisions. Easy to install and integrate with data systems, this weighbridge combines strength, accuracy, and smart connectivity in one comprehensive weighing platform.
Key Features
💪 Heavy-Duty Industrial Construction
- Reinforced structural steel frame with welded I-beam design
- Rugged deck with anti-slip surface for safety and longevity
- Built to withstand high traffic and heavy wheel loads
📊 Accurate & Reliable Weighing
- Precision load cells for stable, repeatable measurements
- Supports gross, net, and axle weight calculations (with software)
- Quick and consistent weight readings even under frequent use
🔧 Modular & Flexible Installation
- Modular deck sections for adaptable lengths and configurations
- Suitable for surface mount or pit mount installations
- Easy access for service and calibration
🖥 Advanced Electronics & Connectivity
- Digital weight indicator with backlit display
- Export data via USB / RS232 / Ethernet (optional wireless)
- Optional printer for weight tickets and reporting
- Integration with fleet or business management systems
🌦 Built for Tough Conditions
- Weather-resistant finishes for outdoor environments
- Sealed load cells protected from dust and moisture
- Corrosion-resistant coatings for long service life
Technical Specifications
|
Specification |
Details |
|
Product Name |
Industrial Truck Scale Weighbridge |
|
Standard Platform Lengths |
6 m, 9 m, 12 m, 15 m (custom lengths available) |
|
Standard Width |
3 m (or custom widths based on requirement) |
|
Maximum Capacity |
Up to 80,000 kg / 100,000 kg / 120,000 kg (model dependent) |
|
Accuracy Class |
OIML Class III or better (±0.5% or as specified) |
|
Deck Construction |
Reinforced structural steel with anti-slip surface |
|
Framework |
Welded I-beam structure |
|
Load Cells |
Sealed alloy steel precision load cells |
|
Indicator Display |
Digital LCD/LED with backlight |
|
Units of Measure |
kg, tonne, lb (selectable) |
|
Power Supply |
AC mains (110–240 V) with optional battery backup |
|
Data Output Options |
USB / RS232; optional Ethernet / Bluetooth / Wi-Fi |
|
Installation Type |
Surface mount or pit mount |
|
Operating Temperature |
–10 °C to +50 °C (model dependent) |
|
Finish |
Weather-resistant paint or galvanised coating |
Note: Specifications can be tailored to your operational needs. Custom capacities, sizes, and advanced features are available on request.
Common Applications
✔ Weighing trucks at logistics and distribution centres
✔ Payload control in mining, quarry, and construction sites
✔ Regulatory compliance weight checks
✔ Ports, cargo terminals, and agricultural operations
✔ Manufacturing and freight handling facilities
Why Choose the Industrial Truck Scale Weighbridge?
- Built for Industry: Robust construction for high-traffic, heavy-load environments.
- Precision You Can Trust: High-accuracy measurements to support compliance and planning.
- Flexible & Scalable: Modular design fits a wide range of site needs.
- Data Ready: Advanced electronics and connectivity for reporting and integration.
- Reliable Support: Backed by experienced installation and service options.
