The High Precision Weighing Sensor is an advanced load sensing component designed to deliver accurate, stable, and reliable weight measurement in industrial, laboratory, commercial, and automation applications. Manufactured using high-quality materials and precision engineering, this weighing sensor ensures consistent performance and long operational life.
This sensor is widely used in digital weighing scales, platform scales, laboratory balances, packaging machines, and automated weighing systems. It is designed to provide excellent sensitivity, fast response time, and superior resistance to environmental disturbances. The compact and durable construction allows easy integration into various weighing equipment. Backed by a 1-year warranty, this weighing sensor offers dependable performance and long-term reliability for professional weighing applications.
Specifications
Type: Load Cell / Weighing Sensor
Capacity Range: 1 kg – 500 kg (model dependent)
Accuracy Class: C2 / C3 (model dependent)
Rated Output: Approx. 2.0 ± 0.2 mV/V
Input Resistance: Approx. 350 Ω ± 10 Ω
Output Resistance: Approx. 350 Ω ± 5 Ω
Insulation Resistance: ≥ 5000 MΩ
Excitation Voltage:
· Recommended: 5 – 12 V DC
· Maximum: 15 V DC
Non-Linearity: ±0.02% F.S.
Hysteresis: ±0.02% F.S.
Repeatability: ±0.01% F.S.
Creep (30 min): ±0.02% F.S.
Construction Material: Alloy Steel / Stainless Steel (model dependent)
Protection Rating: IP65 / IP67 (model dependent)
Operating Temperature: -10°C to 40°C
Safe Overload: 120% of Rated Capacity
Ultimate Overload: 150% of Rated Capacity
Cable Length: Approx. 1 – 3 meters (model dependent)
Cable Type: Shielded cable for noise protection
Applications
· Platform weighing scales
· Industrial weighing systems
· Laboratory weighing machines
· Packaging and batching equipment
· Automation and process control systems
