A digital electronic crane weighing scale is a portable hanging scale designed to measure the weight of suspended loads with precision. It uses an advanced load cell sensor and a backlit LCD display to provide stable, accurate readings. These scales are widely used in warehouses, workshops, shipping yards, agriculture, markets, and industrial settings where overhead weighing is required.
⚖️ Capacity & Performance
|
Specification |
Value (Typical) |
|
Model Type |
Electronic Crane / Hanging Weighing Scale |
|
Weighing Capacity |
100 kg / 200 kg / 300 kg / 500 kg (model dependent) |
|
Resolution |
0.05 kg – 0.1 kg (capacity dependent) |
|
Accuracy |
±0.1% of Full Scale |
|
Load Cell Type |
High‑precision strain gauge load cell |
|
Response Time |
< 3 seconds |
🖥️ Display & Units
|
Feature |
Details |
|
Display Type |
Backlit LCD Digital Screen |
|
Digit Height |
20–30 mm (varies by model) |
|
Weight Units |
kg / lb (selectable) |
|
Display Functions |
Weight Hold, Tare, Zero Indicator, Overload Alert |
🔧 Weighing Functions
✔ Tare Function – Net weight based on container or attachment subtraction
✔ Zero / Auto Zero Tracking – Baseline stability
✔ Hold Function – Locks weight reading
✔ Overload Warning – Alerts when exceeding capacity
✔ Auto Power‑Off – Saves battery when idle
✔ Low Battery Indicator – Alerts for battery replacement
🔋 Power & Efficiency
|
Specification |
Details |
|
Power Source |
Batteries (AAA, AA, or built‑in rechargeable) |
|
Battery Type |
3–4 × AAA / Rechargeable Li‑ion (model dependent) |
|
Battery Life |
~40–100+ hours (approx.) |
|
Auto Sleep |
Yes (configurable) |
|
Low Battery Alert |
Yes |
🛠️ Construction & Materials
|
Feature |
Specification |
|
Housing Material |
ABS Plastic / Aluminum Alloy |
|
Hook Material |
Stainless Steel / Alloy Steel |
|
Safety Latch |
Included |
|
Environmental Protection |
Dust / Splash‑resistant (varies by model) |
|
Operating Temp Range |
−10 °C to +40 °C (typical) |
|
Storage Temp Range |
−20 °C to +50 °C |
📏 Physical Dimensions
|
Feature |
Typical Value |
|
Scale Body Size |
~200 × 120 × 60 mm (varies by model) |
|
Hook Opening Diameter |
~30–40 mm |
|
Net Weight |
~0.7 – 1.5 kg |
|
Packing Weight |
~1.2 – 2.2 kg |
🏭 Typical Applications
✔ Warehouse & logistics weighing
✔ Industrial manufacturing
✔ Construction materials weighing
✔ Agricultural sacks & produce
✔ Parcel and freight handling
✔ Luggage & heavyweight item checking
✔ Fieldwork and portable weighing
📌 Why Choose LCD Digital Crane Scales
- Clear Visibility – Easy reading even in dim lighting or distance
- Portable & Battery Operated – No need for mains power on site
- Accurate & Reliable – Precision load cells minimize error
- Multi‑Functional – Tare, hold, zero, and overload warnings add workflow efficiency
- Durable Build – Rugged housing and safety hook for industrial use
