A compact, high‑precision, light duty digital hanging scale engineered for reliable and durable performance in industrial, commercial, and agricultural use. Suitable for weighing suspended loads in small factories, warehouses, markets, workshops, logistics, and field operations.
⚙️ Technical Specifications
|
Specification Item |
Details |
|
Model Type |
Digital Light Duty Crane Weighing Scale |
|
Capacity Range |
Typically 50 kg / 100 kg / 200 kg / 300 kg / 500 kg |
|
Resolution / Division |
0.05 kg – 0.2 kg (capacity dependent) |
|
Accuracy |
±0.1% – ±0.2% of Full Scale |
|
Display Type |
Digital LCD or LED with backlight |
|
Weighing Units |
kg / lb selectable |
|
Load Cell |
High‑precision strain gauge |
|
Display Digits |
4–6 digits (model dependent) |
|
Response Time |
< 3 seconds typical |
|
Power Supply |
Rechargeable battery or AAA batteries |
|
Battery Life |
~30–80 hours (model dependent) |
|
Functions / Modes |
Tare, Zero, Hold, Backlight, Auto‑off |
|
Overload Protection |
Yes (display warning & safe cutoff) |
|
Housing Material |
ABS plastic or aluminum alloy |
|
Hook Material |
Alloy steel with safety latch |
|
Operating Temperature |
–10 °C to +40 °C |
|
Storage Temperature |
–20 °C to +50 °C |
|
Humidity Range |
10% – 90% RH (non‑condensing) |
|
Ingress Protection |
IP54 – Light dust/splash‑proof (model dependent) |
|
Net Weight (Scale Only) |
~0.5 kg – 1.2 kg |
|
Gross Weight (Packed) |
~1.0 kg – 1.8 kg |
🧰 Functional Features
✔ Tare Function – Subtract container weight for net weight reading
✔ Zero Tracking – Maintains accurate zero baseline
✔ Hold Function – Locks stable weight on display
✔ Auto Power Off – Saves battery when idle
✔ Unit Switching – kg / lb selectable
✔ Low‑Battery Indicator – Alerts when battery is low
✔ Overload Alarm – Displays warning to protect load cell
🏭 Typical Applications
- Warehouses & distribution weighing
- Small factory and workshop load measurement
- Market and agricultural produce weighing
- Parcel & cargo handling
- Light industrial materials handling
🔧 Mechanical / Construction Details
- Chassis: Tough ABS or aluminum housing
- Hook: High‑strength alloy steel with safety lock
- Display: Elevated for clear visibility
- Mounting: Hanging hook compatible with beams, cranes, lifting eyes
- Portability: Easy‑carry compact design
🔋 Power & Battery
- Rechargeable Battery: 3.7 V Li‑ion (typical)
- Battery Charger: Standard wall charger included
- Battery Life: Approx. 40–80 hours under normal load
- Auto‑Sleep: Saves power after inactivity
