The 200,000KG Large Car Electronic Axle Weighing Scale is a heavy-duty industrial weighing system designed for accurate axle-by-axle weight measurement of trucks, trailers, buses, and other large commercial vehicles. Engineered for durability and precision, this system is ideal for highways, logistics depots, border checkpoints, mining sites, construction zones, and freight terminals where vehicle overload control and compliance are critical.
Built with high-strength steel or reinforced concrete platform options, the scale uses advanced digital load cell technology to deliver fast, stable, and highly accurate readings even under extreme load conditions. Its axle-weighing design allows vehicles to be weighed in segments, making it suitable for locations with limited space or high traffic flow.
The system can be integrated with data management software, ticket printing systems, and traffic control barriers for complete weighing automation.
Key Features
- High-capacity axle weighing up to 200,000 kg (200 tons)
- Heavy-duty steel platform or reinforced modular design
- High-precision digital load cells for accurate measurement
- Axle-by-axle weighing for trucks and multi-axle vehicles
- Anti-corrosion and weather-resistant construction
- Fast response time for high traffic efficiency
- Optional integrated indicator display with printer support
- Overload protection and fault diagnostic system
- Suitable for both static and semi-dynamic weighing
Specifications
Product Type: Electronic Axle Weighing Scale (Truck Scale System)
Maximum Capacity: 200,000 kg / 200 tons
Weighing Method: Axle load measurement (static or low-speed dynamic)
Accuracy Class: OIML approved (Class III typical)
Readability: 10 kg – 50 kg (depending on configuration)
Platform Size Options:
- Standard axle pad modules (customizable length)
- Typical module width: 0.8m – 1.2m per lane
Load Cell Type: Digital high-precision compression load cells
Material: Heavy-duty carbon steel / stainless steel coating (optional)
Display Unit: Digital LED/LCD indicator
Power Supply:
- AC 220V / 50–60Hz
- Rechargeable backup battery (optional)
Operating Temperature: -30°C to +70°C
Protection Rating: IP65 – IP68 (load cells depending on model)
Connectivity Options:
- RS232 / RS485
- USB / Ethernet (optional)
- Wireless data transmission (optional)
Installation Type: Surface-mounted or pit-mounted (optional design)
Applications
- Highway vehicle overload control stations
- Logistics and freight terminals
- Mining and quarry operations
- Construction and heavy equipment sites
- Border control and customs checkpoints
- Industrial transport hubs
Optional Features
- Automatic number plate recognition (ANPR) integration
- Traffic light and barrier control system
- Weighing software with database storage
- Remote monitoring and cloud reporting
- Solar-powered system option
