A 120-ton concrete semi-mobile truck scale is a heavy-duty weighing system designed for accurate measurement of loaded trucks and trailers in mining sites, construction zones, quarries, logistics hubs, and industrial facilities. It combines the durability of a reinforced concrete deck with the flexibility of a semi-mobile modular structure, allowing relocation when site layouts change.
Unlike permanent foundation truck scales, this system is engineered for faster installation and partial mobility, while still maintaining high load-bearing capacity and long-term stability under continuous heavy traffic.
It is ideal for operations that require high weighing capacity, rugged performance, and occasional repositioning without the cost and time of full civil reconstruction.
Key Features
- High-capacity weighing up to 120 tons
- Reinforced concrete deck construction for durability and long service life
- Modular semi-mobile design for easier relocation and reinstallation
- High-precision load cell technology
- Anti-corrosion and weather-resistant components
- Suitable for harsh environments (dust, vibration, heavy impact)
- Compatible with digital indicator systems and software integration
- Low maintenance requirements
- Optional automation (RFID, ticket printing, traffic lights)
Technical Specifications
1. Capacity & Accuracy
- Maximum Capacity: 120 tons (120,000 kg)
- Accuracy Class: OIML C3 or better (depending on load cells used)
- Weighing Error Margin: ±0.02% to ±0.05% (typical system range)
2. Platform Structure
- Type: Semi-mobile modular truck scale
- Deck Material: Reinforced concrete slab over steel beam structure
- Surface Finish: Anti-slip industrial-grade concrete surface
- Modular Sections: Typically 3–6 modules depending on length
- Length Options: 12 m – 24 m (customizable)
- Width: 3 m – 3.5 m standard
3. Load Cells
- Type: Compression or shear beam load cells
- Material: Alloy steel / stainless steel (optional)
- Protection Rating: IP68 / IP69K (dust and waterproof)
- Quantity: 6–12 load cells depending on platform size
4. Foundation & Mobility
- Foundation Type: Shallow concrete pads or steel support base
- Mobility: Semi-mobile (can be dismantled and relocated using lifting equipment)
- Installation Time: Faster than permanent concrete pit systems
- Reusability: High (designed for multiple relocations)
5. Electrical & Indicator System
- Indicator Type: Digital weight indicator with LCD/LED display
- Power Supply: 220V / 110V AC, 50–60 Hz
- Communication: RS232 / RS485 / USB / optional wireless
- Software: Truck weighing management system compatible
6. Environmental Conditions
- Operating Temperature: -30°C to +70°C
- Humidity Resistance: Up to 95% non-condensing
- Protection Class: IP65–IP68 system-dependent
7. Optional Add-ons
- RFID vehicle identification system
- Automated ticket printing system
- CCTV monitoring integration
- Traffic lights and boom barriers
- Remote data monitoring (cloud-based system)
- Solar power backup option
